Surveying Road Mini Circular Prism Tunnel Prism for Total Stations, Mini Prism Applicable to Subway Monitoring

Model: ADSmini112-1

Specifications:

Features:

· Tunnel Prism for Total Stations Prism diameter: 12.7mm.

· The plastic holder is 15cm diameter

· Mini Prism Applicable Measuring range: 600m

· Mini Prism Applicable to Subway Monitoring Surveing Mini Prism

· Mini Prism With Carrying Case, Glass Protector

Overview:

Leosurvey High Accuracy Single Road Monitoring Prism features a housing that is manufactured from a special nylon thermoplastic blend which offers superior strength and longevity, that provides substantial cost savings.

It contains a 12.7 mm high accuracy optical coated prism. It is extremely durable and designed to withstand highway traffic when adhered to roadway using any approved AASHTO rated adhesive.

The prism located inside the housing is angled at 10° with line-of-sight the AMTS.

The road prism can accommodate misalignments within ± 10°. For example, the 20° road prism is usable with angles between 10° to 30°.

The 10° road prisms are used with AMTS which are secured on tripods. 20° prisms are used with AMTS mounted on buildings 3 to 7 stories high, and 40° prisms are used with AMTS mounted on buildings 8+ stories high.

Leosurvey Instrument Co.,Ltd is a professional surveying accessories supplier in China. Items we supply covers:

1. Prisms (reflector prism, prism set, 360 degree prism, mini prism)

2. Prism Pole, Bipods and Tripods

3. Levelling Staff (Invar, Manganese, Aluminum)

4. Tripods (Aluminum, Wooden, Fiberglass)

5. Tribrach and Adaptors

6. Battery, cable and Chargers of different brands

7. GNSS pole and accessories

Our mission is to supply high quality and excellent service for our customers and partners. Meanwhile, we can custom-make products for our clients with different requirements. We are looking for reliable distributors all around the world, welcome to contact us for more!
