    Reflectorless 1000m Surveying Total Station With Dual Axis

    Ask Lasest Price
    Brand Name : FOIF
    Model Number : RTS112SR10
    Certification : ISO
    Price :
    Payment Terms : T/T
    Supply Ability : 100 pieces per month
    Delivery Time : 10~20 Work Day
    • Product Details
    • Company Profile

    Reflectorless 1000m Surveying Total Station With Dual Axis

    Total Station Reflectorless 1000m Surveying Instrument FOIF RTS112SR10 2'' Accuracy


    Model: RTS112SR10


    Specification:

    ModelRTS112SR10
    ImageErect
    Magnification30X
    Shortest Focus Distance1.0m
    Reading SystemAbsolute encoder
    Accuracy of RTS6802’’
    Prism1.0-1.5s
    Measuring Range2.0 to 600m (800m optional)
    Prism Accuracy1.5mm+2ppm
    Measuring TimeInitial: 2.5sec
    CompensatorDual-axis
    Setting Accuracy1’’
    Plate Level Vial30’’/2mm
    Circular Level Vial8’/2mm
    Laser Plummet Accuracy1mm/1.5m
    Optical Plummet Accuracy0.8mm/1.5m
    Battery3400mAh Li-ion Rechargeable
    Output Voltage7.4V DC
    Operation Time12 Hours
    ChargerFDJ6-LI(11v/24v)
    Charging Time4 Hours
    DisplayLarge LCD (240*128 dots)
    CPU32Bit
    Memory128M internal memory, support SD card
    KeyboardAlphanumerical, both sides
    Weight15Kg
    Dimension185*220*360mm
    Data Transfer SoftwareFOIF Geomatics Office
    Water and dust ProtectionIP55

    Total Station

    FOIF provides total station solutions to meet all your surveying needs. Measurements have never been so easy to perform as with the FOIF Total Station, which allows beginners and professionals to do the job quickly and efficiently.

    Overview of RTS100 Series Total Station

    1. Alphanumeric Keyboard

    2. Reflectorless measuring distance: 600m(R600)

    3. Bluetooth cable-free connection (Factory Optional)

    4. 120000 points and 40 jobs can be saved.

    5. Can be operated with a data collector, FOIF FieldGenius, or other third party software is available.


    Overview:

    A. EDM technology is improved, its powerful long reflectorless measuring distance can reach 600m/1000m

    B. Power long reflectorless measuring distance 1000m

    C. Bluetooth cable-free connection

    D. 128Mb internal memory, 120000 points and 40 jobs can be saved

    E. Can be operated with a data collector, FOIF FieldGenius or Carlson SurvCE

    F. IP66 environmental protection

    G. Alphanumeric keyboard


    Features:

    A. Dual Screen

    B. SD card, Bluetooth

    C. USB, RS232

    D. Two Batteries with over 26 hours of working time


    Package: Hard Carrying Case
